1-10t/h Double Ring Die Poultry Feed Machine

2.5mm-10mm
Feed size
380V/22V
Voltage
1 Year
warranty
Product Description

Ring-die Poultry Feed Pellet Mill Machine Introduction:
Lima Ring-die poultry feed pellet mill machine is designed and manufactured by adopting mature and advanced technology to produce quality animal feed pellets for chicken, cattle, rabbit, horse, duck, and pet animals, etc. It has high capacity for large-scale production requests. And it is an ideal equipment for animal and poultry breeding factory, livestock farm, poultry farm, individual farmers, feed processing industry, etc.



Product Detail





Feed Pellet






Packing&Shiping



Exhibition



Features
The cutting system adopts the cutter shaft positioning spring and cutting mode to achieve stepless speed change, which can cut the output to any desired length.
Easy to install, easy to disassemble, easy to disassemble, and easy to operate.
The screw are made of a special wear-resistant high-temperature and high-humidity material, 38 chromium molybdenum aluminum, which is tempered and then heat-treated to form, which has the advantages of wear resistance and long life.
Equipped with a unique pressurized die device to ensure feed yield and quality.
WHY CHOOSE OUR CHICKEN FEED EXTRUSION MACHINE?
01
How can I know the status of my order?
We will send you photos and videos of your order at different stage in time and keep you informed of the latest information. And about shipping information we will following , we also can give you shipping company website you can following any time .
02
How about the “Quality Assurance”?
Our company has been established for more than ten years. And all machine before shipping we have professional apartment to test and adjust for you ,and we also have certificate SGS ,PC ,SONCAP, it is keep machine good quality, and Nigeria we have partner can help you solve all problems and , in Abuja we have warehouse you also can going for check machine
03
How can I know the status of my order?
We will send you photos and videos of your order at different stage in time and keep you informed of the latest information. And about shipping information we will following , we also can give you shipping company website you can following any time
parameter
Type Capacity(kg/h)             Main power Modulator Power(each layer) Feeder power Size (Single-layer modulator) Size (Double layer       modulator) Weight  (single layer modulator) Weight  (double layer modulator)
HKJ25C 1-2t/h 22kw 1.1kw 0.75kw 1700×650×1750mm 1700×650×2100mm 715kg 850kg
HKJ32 2-5t/h 22kw×2 2.2kw 0.75kw 1800×1550×1650mm 1800×1550×2000mm 1400kg 1600kg
HKJ35 3-7t/h 30kw×2 2.2kw 0.75kw 2150×1950×1900mm 2150×1950×2270mm 2000kg 2200kg
HKJ40 4-10t/h 45kw×2 4kw 1.5kw 2300×2000×2020 2300×2000×2455 2500kg 2800kg
HKJ45 6-12t/h 55kw×2 4kw 1.5kw 2300×2330×2090 2300×2330×2525 3200kg 3500kg
HKJ508 8-15t/h 75kw×2 5.5kw 1.5kw 3350×2350×2200 3350×2350×2630 4300kg 4750kg
